1734-IR2 Allen-Bradley INPUT MODULE

Resolution 16 bits
9.5 mΩ/cnt
0.03 °C/cnt (Pt385 @ 25 °C)
[0.05 °F/cnt (Pt385 @ 77 °F)]
16 bits
2.4 mΩ/cnt
0.006 °C/cnt (Pt385 @ 25 °C)
[0.0114 °F/cnt (Pt385 @ 77 °F)]
Input range 0…600 Ω 0…220 Ω
Sensors supported 100 Ω Pt, α = 0.00385 Euro
-200…870 °C (-328…1598 °F)
200 Ω Pt, α = 0.00385 Euro
-200…630 °C (-328…1166 ° F)
100 Ω Pt, α = 0.003916 U.S.
-200…630 °C (-328…1166 °F)
200 Ω Pt, α = 0.003916 U.S.
-200…630 °C (-328…1166 °F)
10 Ω Cu, α = 0.00427
-200…260 °C (-328…500 °F)
100 Ω Ni, α = 0.00618
-60…250 °C (-76…482 °F)
120 Ω Ni, α = 0.00672
-60…250 °C (-76…482 °F)
120 Ω Ni, α = 0.00618
-60…250 °C (-76…482 °F)
100 Ω Pt, α = 0.00385 Euro
-50…320 °C (-58…608 °F)
Absolute accuracy(1)(2) 0.1% Full Scale @ 25 °C (77 °F)
Accuracy drift with temp(2). 30 ppm/°C
Input update rate (per module) 40 ms @ Notch = 50 Hz
33 ms @ Notch = 60 Hz (default)
20 ms @ Notch = 100 Hz
17 ms @ Notch = 120 Hz
10 ms @ Notch = 200 Hz
8 ms @ Notch = 240 Hz
7 ms @ Notch = 300 Hz
5 ms @ Notch = 400 Hz
4 ms @ Notch = 480 Hz
Step response (per channel) 60 ms @ Notch = 50 Hz
50 ms @ Notch = 60 Hz
30 ms @ Notch = 100 Hz
25 ms @ Notch = 120 Hz
15 ms @ Notch = 200 Hz
13 ms @ Notch = 240 Hz
10 ms @ Notch = 300 Hz
8 ms @ Notch = 400 Hz
6 ms @ Notch = 480 Hz
Conversion type Delta Sigma
Common mode rejection ratio 120 dB
Normal mode rejection ratio 100 dB
Notch filter -3 dB settable at the following:
13.1 Hz @ Notch = 50 Hz
15.7 Hz @ Notch = 60 Hz
26.2 Hz @ Notch = 100 Hz
31.4 Hz @ Notch = 120 Hz
52.4 Hz @ Notch = 200 Hz
62.9 Hz @ Notch = 240 Hz
78.6 Hz @ Notch = 300 Hz
104.8 Hz @ Notch = 400 Hz
125.7 Hz @ Notch = 380 Hz
Data format Signed integer
Maximum overload No input protection
Calibration Factory calibrated
