1769sc-if8u Allen-Bradley

1769sc-if8u Allen-Bradley 8 Ch Universal Analog Module

Packaging & Delivery

Product Details

 Inputs per Module 8 (eight) V,C,TC; 4 (four) RTD, Resistance
 Module Location CompactLogix 1769 , MicroLogix 1500
 Input Types
Thermocouple J, K, T, B, E, R, S, N, C
RTD PT385/3916, Ni618/672, NiFe518, Cu 426
Resistance 0-150, 0-1000, 0-3000 ohm
Current 0-20 mA, 4-20 mA
Voltage ±50mV, ±100mV, 0-5V, 1-5V, 0-10V, ±10V
 Advanced Features 6 filter frequencies (individually selectable by channel);
fully auto-calibration; on-board error checking;
open circuit detection for most input types
 Update Times* 2.44 sec @ 10 Hz
 With eight channels enabled 0.53 sec @ 50 Hz
 * = TC update times may be longer 0.45 sec @ 60 Hz
0.15 sec @ 250 Hz
0.09 sec @ 500 Hz
0.07 sec @ 1000 Hz
 Communication Formats 16-bit two’s complement
Engineering units, Engineering units x10
Scaled for PID, Proportional Count
 Electrical Isolation ±10 Vdc channel-to-channel
(continuous) 500 Vdc field-wiring-to-backplane
500 Vdc field-wiring-to-chassis-ground
 Input Impedance >10 Mohm Thermocouple, Voltage, RTD
<250 ohm, Current
