1797-TB3 Allen-Bradley TERMINAL BASE UNIT

Item NO.:
1797-TB3
Payment:
T/T 、PayPal、Western Union
Product Origin:
United States
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

1797-TB3 Allen-Bradley TERMINAL BASE UNIT

Brand：Allen-Bradley	Model number：1797-TB3
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: United States
Price: Please contact us	Product weight：0.23kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Number of Terminals 1 row of 16, 2 rows of 18
1797-TB3 Terminal Screw Torque 0.8…1.0 Nm (7…9 lb-in)
1797-TB3S Terminal Type Spring-clamp - To open, insert bladed screwdriver
(2.54-3.05 mm/0.100-0.120 in.) and lift up.
Terminals Assignments1
+34, -35, +50, -51, and 96
Pini
Female I/O Connector
Pinsi
30…32, 62…64, 94…96,
36, 49
All Other Terminals
Only for intrinsically safe circuits
Ui <10V dc
I
i <2.5 A
Ci < 1 nF
Li Negligible
Must not be used for any connection
Ui <30V dc
I
i <100 mA
Ci <1 nF
Li Negligible

Flexbus Connection
Intrinsically Safe
Ui <10V dc
I
i <400 mA
Ci <1 nF
Li Negligible
Isolation Voltage Channel-to-channel isolation determined by inserted
module
Weight 200 g (approximately)
Dimensions (With Module Installed
in Base) Metric
Imperial
3.7H x 3.7W x 2.7D mm
(94H x 94W x 69D in.)
Environmental Conditions
Operational Temperature -20…70 o
C (-4…158 o
F)
Storage Temperature -40…85 o
C (-40…185 o
F)
Relative Humidity 5…95% noncondensing
ShockOperating Tested 15 g peak acceleration, 11 (±1) ms pulse width
Nonoperating Tested 15 g peak acceleration, 11 (±1) ms pulse width
Vibration Tested 2 g @ 10…500 Hz per IEC 68-2-6
Conductors Wire Size 4 mm2 (12 gauge) stranded max
1.2 mm (3/64 in.) insulation max
