CC-PAIH02 Honeywell INPUT MODULE

Parameter Specification
Normal Mode Filter Response Single-pole RC, -3 dB @ 6.5 Hz
Maximum Normal Mode Input (differential inputs, no
damage)
± 30 Volts
Crosstalk, dc to 60 Hz (channel-to-channel) -60 dB
Input Impedance (voltage inputs) > 10 M Ω powered
Input Scan Rate 50 ms
Hardware Accuracy (@ CMV = 0 V) ± 0.075% of full-scale (23.5°± 2°C)
± 0.15% of full-scale (0 to 60°C)
Transmitter Field Power Conditioning Individually Protected Current Limiting Circuits for Class 1,
Div 2 non-incendive interfacing. No fusing required
Note 1: CC-PAIH01 supports voltage inputs for channels 13-16 CC-PAIH02 supports voltage inputs for channels 1-16 when used
with CC-TAIDx1 IOTA. Each channel's 250-Ohm load resistor is connected to the input terminal through a wire jumper on
the IOTA. This jumper should be cut by the user on channels to be used with voltage transmitters. For channels 13-16 the
low-side input connection is normally connected to system common by a wire jumper on the IOTA. This jumper may be cut
by the user to enable differential operation subject to operating within the CMV specification.
