The SICK FX3-CPU000000 is the central processing unit (CPU0) module for the highly regarded Flexi Soft modular safety controller system. It serves as the "brain" of the safety system, executing the safety logic programmed via the Flexi Soft Designer software.

Unlike other modules in the CPU family (like CPU1 or CPU3), the CPU0 is a streamlined, cost-effective main module designed for systems that do not require SICK’s proprietary EFI (Enhanced Functional Interface) communication ports.

1. Technical Parameters

The following table highlights the core electrical, mechanical, and safety-related specifications of the FX3-CPU000000:

Parameter	Specification / Value	Notes
Module Type	Main CPU Module (CPU0)	Part of SICK Flexi Soft family
Safety Integrity Level	SIL 3 (IEC 61508) / SILCL 3 (EN 62061)	Highest safety capability
Performance Level	PL e (EN ISO 13849-1)	Category 4 compliant
$PFH_D$ (Probability of Dangerous Failure/hr)	$1.07 \times 10^{-9}$	Highly reliable
Mission Time ($T_M$)	20 Years	Standard lifetime rating
Supply Voltage ($U_V$)	$24\text{ V DC}$ ($16.8\text{ V}$ to $30\text{ V DC}$)	PELV or SELV power source required
Internal Power Consumption	$\le 2.5\text{ W}$	Energy-efficient design
EFI Interfaces	0	No SICK EFI ports on this variant
Connection Type	Plug-in spring terminals	Located on the separate system plug
Configuration Interface	RS-232 (M8 female socket, 4-pin)	Front-facing programming port
Dimensions (W x H x D)	$22.5\text{ mm} \times 96.5\text{ mm} \times 120.6\text{ mm}$	Compact, DIN-rail mountable
Enclosure Rating	IP20 (EN 60529)	Designed for control cabinet use
Operating Temperature	$-25\ ^\circ\text{C}$ to $+55\ ^\circ\text{C}$	Broad industrial temperature tolerance

2. Product Advantages

• Highly Modular & Scalable: By acting as the core of the Flexi Soft system, this CPU allows you to easily scale your safety setup. You can attach up to 12 expansion modules (digital I/O, analog inputs, relay outputs, or fieldbus gateways) based on your system requirements.

• Cost-Efficient Safety Brain: Because it omits the EFI ports, the CPU0 is a more economical choice for standalone safety setups that don't need to link multiple SICK safety scanners or smart sensors directly via EFI.

• Easy Programming via Flexi Soft Designer: System configuration is done using SICK’s free, license-free, intuitive drag-and-drop programming software. It simplifies safety logic creation (AND, OR, bypass, muting, etc.).

• Integrated Diagnostic Memory: Features an internal memory configuration that saves error logs and event histories, making system diagnostics and troubleshooting exceptionally fast and easy.

• Compact Footprint: At only $22.5\text{ mm}$ wide, the module maximizes space in crowded electrical control panels.
