TH8320R1003 Honeywell WiFi Thermostats

Applications: Up to 1 Heat/1 Cool heat pump or up to 1 Heat/1 Cool
conventional
Display Size: 10 sq in.
Color: Arctic White
Changeover: Auto or Manual
Stages: Up to 4 Heat / 2 Cool Heat Pump or Up to 3 Heat / 2 Cool
Conventional when used with the Equipment Interface Module.
Programmability: 7-Day Multiple Day Programming or
Non-Programmable
Switch Positions (System): HEAT-OFF-COOL-AUTO
Switch Positions (Fan): AUTO-ON-CIRC-FOLLOW SCHEDULE
Setting Temperature Range: Heat: 40°F to 90°F; Cool 50°F to 99°F
(Heat: 4.5°C to 32.0°C; Cool: 10°C to 37.0°C)
Operating Temperature Range: 32°F to 120°F (0°C to 48.9°C)
Operating Humidity Range (% RH): 5 to 90% RH, non-condensing
Power Method: Battery or Hardwired (must be battery powered when
used on a millivolt system)
Supply Voltage: 18 to 30 Vac
Frequency: 50 Hz; 60 Hz
Electrical Connections: Screw terminals
Electrical Ratings: 18 to 30 Vac or 750 mV
Dimensions: 4 5/8 in. High, 4 15/16 in. Wide, 1 1/8 in. Deep (118 mm.
High, 126 mm. Wide, 29 mm. Deep)
Used With: Works standalone or with optional THM5421R1021
Equipment Interface Module and RedLINK™ accessories
